Product Info
- Manufacturer:American/Federal Pacific
- Sub-Category:Low Voltage Fuse
Description
OTS80
OTS80 is a Federal Pacific low voltage fuse rated for 80 amperes and 600 volts AC, designed for fast-acting circuit protection.OTS80 fuse features a cylindrical body with a 1.31 inch diameter and is classified as a UL Class K5 fuse. It is a one-time, non-rejection type fuse suitable for protecting circuits serving non-inductive or slightly inductive loads. The fuse has an interrupt rating of 50,000 amperes and is ROHS compliant.
- Key Specifications
- Amperage: 80 A
- Voltage Rating: 600 VAC / 300 VDC
- Fuse Class: K5
- Speed: Fast-Acting
- Interrupt Rating: 50 kA
- Poles: 1
- Mounting Type: Cylindrical Barrel
- Diameter: 1.31 inches
- One-Time Use
- Non-Rejection Type
- ROHS Compliant
Specifications
- Part Number: OTS80
- Manufacturer : American/Federal Pacific
- Brand : American/Federal Pacific
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : OTS Series
- Type : OTS
- Voltage : 600
- Amperage : 80
- AIC rating : 50kA@600V
- Diameter : 1.31
- Class Rating : K-5
- Barrels : 1
Product Data
- UPC : 078200170084
- GTIN : 00782001700843
- Country of Origin : Mexico
- Dimensions : x 7.88 in x
- Weight : 0.55
