OTS70 - Federal Pacific 70A 600V Class K5 Low Voltage Fast Acting Fuse

OTS70

OTS70 is a Federal Pacific low voltage fast acting fuse rated for 70 amps and 600 volts AC. It is designed for reliable circuit protection in industrial and commercial applications.OTS70 features a cylindrical body with a 1.31 inch diameter and is classified as a Class K5 fuse with a one-time use rating. It has an interrupt rating of 50 kA at 600 VAC and 20 kA at 300 VDC, providing high fault current protection. This fuse is non-rejection type and suitable for branch circuit protection in non-inductive or slightly inductive loads.

Key Specifications
• Amperage: 70 A
• Voltage Rating: 600 VAC / 300 VDC
• Fuse Class: K5
• Interrupt Rating: 50 kA AC / 20 kA DC
• Body Type: Cylindrical (PolyTube)
• Diameter: 1.31 inches
• Fuse Type: One-Time Use
• Mounting Type: Inline Fuse Holder
• Certifications: UL Listed
• Manufacturer: Federal Pacific (Mersen)
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: OTS70
• Manufacturer : American/Federal Pacific
• Brand : American/Federal Pacific
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : OTS Series
• Type : OTS
• Voltage : 600
• Amperage : 70
• AIC rating : 50kA@600V
• Diameter : 1.31
• Class Rating : K-5
• Barrels : 1



Product Data

• UPC : 782001700829
• GTIN : 00782001700829
• Country of Origin : Mexico
• Dimensions : x 7.88 in x
• Weight : 0.55
