Product Info
- Manufacturer:Bussmann
- Sub-Category:Switches
Description
OT80FT3
OT80FT3 is a 3-pole, 80 amp, 600 volt door mounted disconnect switch from Bussmann's OT SwitchLine series.OT80FT3 features a front-operated, non-fusible design suitable for motor control applications. It supports up to 40 hp at 480 V and complies with UL 508, CSA C22.2 No. 14, and IEC 60947-3 standards. The switch has screw terminals, a 6000 V interrupt rating, and is designed for door mounting with a compact frame size.
- Key Specifications
- Amperage: 80 A
- Voltage Rating: 600 V
- Poles: 3
- Mounting Type: Door Mounted
- Interrupt Rating: 6000 V
- Series/Frame: OT SwitchLine
- Trip Unit: Non-fusible
- Standards: UL 508, CSA C22.2 No. 14, IEC 60947-3
- Horsepower Rating: 40 hp at 480 V
- Terminal Type: Screw Terminals
- Operating Mechanism: Front Operated
- Dimensions (HxWxD): 72 mm x 65 mm x 69 mm
Specifications
- Part Number: OT80FT3
- Brand : Bussmann
- Category : Motor Control
- Item Subcategory : Switches
- Section : Disconnect switch
- Family : OT SwitchLine
- Voltage : 600 600
- Compatible Frames : SELA
Product Data
- UPC : 6417019393667
- Dimensions : 72 mm H x 65 mm W x 69 mm D
- Weight : 2
