NOS-90 - Eaton Bussmann 90 Amp 600 VAC Class H One Time Fuse

NOS-90

NOS-90 is a 90 Amp, 600 VAC Class H one-time fuse from Eaton Bussmann designed for general purpose circuit protection.This NOS series fuse offers non-current-limiting, one-time operation with a 10 kA interrupting rating at 600 VAC. It features a blade end connection and measures approximately 1.34 inches in diameter by 7.90 inches in length. The fuse is UL Listed (Class H), CSA Certified, and CE marked, suitable for use in a variety of industrial and commercial applications.

Key Specifications
• Amperage: 90 A
• Voltage Rating: 600 VAC
• Fuse Type: One Time
• Class: H
• Interrupt Rating: 10 kA
• Size: 1.34 in Diameter x 7.90 in Length
• Connection: Blade End
• Agency Certifications: UL Listed, CSA Certified, CE
• Mounting Type: Cartridge style
• Series: NOS
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: NOS-90
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : NOS Series
• Type : NOS
• Voltage : 600
• Amperage : 90
• AIC rating : 10kA@600V
• Diameter : 1.34
• Class Rating : H
• Barrels : 1



Product Data

• UPC : 051712310901
• GTIN : 00051712310901
• Country of Origin : Mexico
• Dimensions : 7.9 in x 1.34 in x 1.34 in (Length/Depth x Height x Width)
• Weight : 0.55
• Certification : CE, UL Listed, Guide JDDZ, File E4273, STD 248-6, CSA Certified Class 1421-01, File 53787
