NOS-80 - Eaton Bussmann 80A 600V Class H One-Time General Purpose Fuse, Non-Current Limiting

NOS-80

NOS-80 is an Eaton Bussmann series Class H general purpose, one-time, non-current-limiting fuse rated for 80 amps and 600 volts AC.This NOS-80 fuse features a blade end connection type and an interrupting rating of 10 kA at 600 VAC. It is designed for light duty circuit protection with Class K5 and Class H ratings, compliant with UL Guide JDDZ and CSA certifications. The fuse measures 7.9 inches in length and 1.34 inches in width and height, making it suitable for standard fuse holders.

Key Specifications
• Amperage: 80 A
• Voltage Rating: 600 V AC
• Interrupting Rating: 10 kA at 600 VAC
• Fuse Class: Class H, Class K5
• Fuse Type: One-time, Non-current-limiting
• Connection: Blade end x blade end
• Dimensions: 7.9 in length, 1.34 in width and height
• Certifications: UL Listed, CSA Certified, CE Marked
• Non-indicating fuse
• Weight: 0.55 lb
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: NOS-80
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : NOS Series
• Type : NOS
• Voltage : 600
• Amperage : 80
• AIC rating : 10kA@600V
• Diameter : 1.34
• Class Rating : H
• Barrels : 1



Product Data

• UPC : 051712310802
• GTIN : 00051712310802
• Country of Origin : Mexico
• Dimensions : 7.9 in x 1.34 in x 1.34 in (Length/Depth x Height x Width)
• Weight : 0.55
• Certification : CE, UL Listed, Guide JDDZ, File E4273, STD 248-6, CSA Certified Class 1421-01, File 53787
