NOS-6 - Eaton Bussmann 6A 600VAC Class K5 Cartridge Fuse 50kA

NOS-6

NOS-6 is a 6-ampere, one-time, non-current-limiting cartridge fuse rated for 600 volts AC with a 50 kA interrupting rating. NOS-6 is designed for light-duty circuit protection applications and is classified as Class K5 and Class H per industry standards. This ferrule-end cartridge fuse provides reliable overcurrent protection in low-voltage power distribution systems.

• Amperage Rating: 6A
• Voltage Rating: 600 VAC
• Interrupt Rating: 50 kA at 600 VAC
• Fuse Type: One-Time, Non-Current-Limiting
• Fuse Class: K5 / Class H
• Body Style: Cartridge with Ferrule Ends
• Speed: Non-Time Delay
• Application: Light-Duty Circuit Protection

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: NOS-6
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Voltage : 600
• Amperage : 6
• AIC rating : 50kA@600V
• Diameter : 1.34
• Class Rating : RK5
• Barrels : 1

Product Data

• UPC : 051712310062
• GTIN : 00051712310062
• Country of Origin : Mexico
• Dimensions : 5 in x 0.81 in x 0.81 in (Length/Depth x Height x Width)
• Weight : 0.153
• Certification : CE, UL Listed, Guide JDDZ, File E4273, STD 248-9, CSA Certified Class 1421-01, File 53787
