NOS-4 - Eaton 4 Amp 600 VAC Class K5 Time-Delay Fuse

NOS-4

NOS-4 is a 4 amp, 600 VAC Class K5 time-delay fuse from Eaton designed for supplemental circuit protection.This Eaton NOS-4 fuse is a one-time, non-current-limiting cartridge fuse with a 50 kA interrupting rating at 600 VAC. It is part of the NOS series, suitable for light-duty circuit protection applications requiring slow-blow characteristics. The fuse is UL Listed, CSA Certified, and CE Marked, ensuring compliance with industry safety standards.

Key Specifications
• Amperage: 4 A
• Voltage Rating: 600 VAC
• Interrupting Rating: 50 kA at 600 VAC
• Fuse Type: Cartridge, one-time fuse
• Class: K5
• Response Time: Time-delay (slow blow)
• Certifications: UL Listed, CSA Certified, CE Marked
• Mounting Type: Cartridge style
• Series: NOS
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: NOS-4
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : NOS Series
• Type : NOS
• Voltage : 600
• Amperage : 4
• AIC rating : 50kA@600V
• Diameter : 0.81
• Class Rating : K5
• Barrels : 1



Product Data

• UPC : 051712310086
• GTIN : 00051712310086
• Country of Origin : Mexico
• Dimensions : 5 in x 0.81 in x 0.81 in (Length/Depth x Height x Width)
• Weight : 0.073
• Certification : CE, UL Listed, Guide JDDZ, File E4273, STD 248-9, CSA Certified Class 1421-01, File 53787
