Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
NOS-175
NOS-175 is an Eaton Bussmann series Class H one-time fuse designed for general purpose circuit protection.
This non-current-limiting fuse features a 175 ampere rating and a voltage rating of 600 volts AC. It has an interrupting rating of 10,000 amperes at 600 volts AC, suitable for light duty circuit locations. The fuse is non-indicating with pin-indicating features and measures 9.63 inches in length with a compact 1.84 inch width and height.
- Key Specifications
- Amperage Rating: 175 A
- Voltage Rating: 600 V AC
- Interrupt Rating: 10 kAIC at 600 Vac
- Class: Class H
- Fuse Type: One-Time, Non-Current-Limiting
- Fuse Indicator: Non-Indicating, Pin-Indicating
- Length: 9.63 in
- Width: 1.84 in
- Height: 1.84 in
- Weight: 1.2 lb
- Compliance: CE Marked
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: NOS-175
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Voltage : 600
- Amperage : 175
- AIC rating : 10kA@600V
- Diameter : 1.84
- Class Rating : RK5
- Barrels : 1
Product Data
- UPC : 051712311755
- GTIN : 00051712311755
- Country of Origin : Mexico
- Dimensions : 9.63 in x 1.84 in x 1.84 in (Length/Depth x Height x Width)
- Weight : 1.2
- Certification : CE, UL Listed, Guide JDDZ, File E4273, STD 248-6, CSA Certified Class 1421-01, File 53787
