NON-5 - Eaton Bussmann 5 Amp 250 Volt Class K5 One-Time General Purpose Fuse 50kAIC Interrupt Rating

NON-5

NON-5 is a 5 Amp, 250 Volt Class K5 one-time general purpose fuse from Eaton Bussmann series designed for reliable circuit protection.This NON-5 fuse features a non-current-limiting design with a 50 kA interrupting rating at 250 Vac and 125 Vdc, ferrule end connections, and a compact size of 0.56" x 2". It is UL Listed, CSA Certified, and CE Marked for safety compliance.

• Amperage Rating: 5 A
• Voltage Rating: 250 Vac, 125 Vdc
• Interrupt Rating: 50 kAIC at 250 Vac, 50 kAIC at 125 Vdc
• Class K5 fuse, one-time use
• Non-current-limiting
• Connection Type: Ferrule end x ferrule end
• Physical Size: 0.56" diameter x 2" length
• Fuse Indicator: Non-indicating
• Certifications: UL Listed, CSA Certified, CE Marked
• Packaging: Standard

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: NON-5
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : NON Series
• Type : NON
• Voltage : 250
• Amperage : 5
• AIC rating : 50kA@250V
• Diameter : 0.56
• Class Rating : K5
• Barrels : 1

Product Data

• UPC : 051712300056
• GTIN : 00051712300056
• Country of Origin : Mexico
• Dimensions : 2 in x 0.56 in x 0.56 in (Length/Depth x Height x Width)
• Weight : 0.35
• Certification : CE, UL Listed, Guide JDDZ, File E4274, STD 248-9, CSA Certified Class 1421-01, File 53787
