NON-40 - Bussmann Eaton NON Series 40A 250VAC 125VDC Class H Non-Current-Limiting Fuse

NON-40

NON-40 is a 40A, 250VAC/125VDC, non-current-limiting, one-time fuse from the Bussmann Eaton NON Series, designed for general purpose circuit protection. This fuse features a ferrule end connection, non-indicating design, and is suitable for use in a wide range of industrial and commercial applications. It offers reliable protection with a 50 kAIC interrupt rating at both 250VAC and 125VDC, and is CE marked for compliance.

• Amperage Rating: 40A
• Voltage Rating: 250VAC, 125VDC
• Interrupt Rating: 50 kAIC
• Class: Class H
• Fuse Type: Non-current-limiting, one-time
• Connection Type: Ferrule end x ferrule end
• Indicator: Non-indicating
• Mounting Type: Standard fuse block compatible
• Series: NON Series
• Compliance: CE Marked
• Dimensions: 3" L x 0.81" W x 0.81" H
• Weight: 0.01 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: NON-40
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : NON Series
• Type : NON
• Voltage : 250
• Amperage : 40
• AIC rating : 50kA@250V
• Diameter : 0.81
• Class Rating : K5
• Barrels : 1

Product Data

• UPC : 051712101615
• GTIN : 00051712101615
• Country of Origin : Mexico
• Dimensions : 3 in x 0.81 in x 0.81 in (Length/Depth x Height x Width)
• Weight : 0.01
• Certification : CE, UL Listed, Guide JDDZ, File E4274, STD 248-9, CSA Certified Class 1421-01, File 53787
