Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
NON-250
NON-250 is a 250 Amp, 250 Volt, Class K5 one-time general purpose fuse from Bussmann Eaton designed for reliable circuit protection.This NON-250 fuse features a non-current limiting design with a 10,000 A interrupting rating at 250 VAC. It is a center-slotted, general purpose fuse suitable for low voltage applications requiring a one-time fuse solution.
- Key Specifications
- Amperage: 250A
- Voltage Rating: 250V AC
- Class: K5
- Interrupting Rating: 10,000 AIC at 250 VAC
- Fuse Type: One-Time, Non-Current Limiting
- Mounting Type: Center Slotted
- Poles: Single Pole
- Certifications: UL Listed
- Part Number: NON-250
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : NON Series
- Type : NON
- Voltage : 250
- Amperage : 250
- AIC rating : 10kA@250V
- Diameter : 2.06
- Class Rating : H
- Barrels : 1
- UPC : 051712302500
- GTIN : 00051712302500
- Dimensions : 8.63 in x 2.06 in x 2.06 in (Length/Depth x Height x Width)
- Weight : 1.65
