NON-25 - Eaton Bussmann 25 Amp 250V NON Class K5 One-Time Fuse

NON-25

NON-25 is a 25 Amp, 250 Volt AC, one-time, non-current-limiting fuse from Eaton Bussmann series designed for general purpose circuit protection.This NON-25 fuse features a Class K5 rating, 50,000 A interrupting rating at 250 VAC and 125 VDC, and complies with UL Std. 248-9 and CSA certification. It measures 0.56" x 2" and is suitable for low voltage branch circuit applications requiring reliable, single-use protection.

Key Specifications
• Amperage: 25 Amps
• Voltage Rating: 250 VAC / 125 VDC
• Fuse Type: One-Time, Non-Current-Limiting
• Class: K5 (0-60A)
• Interrupting Rating: 50,000 AIC RMS at 250 VAC and 125 VDC
• Physical Size: 0.56" x 2"
• Standards: UL Listed (Std. 248-9), CSA Certified
• Mounting Type: Cartridge style
• Manufacturer: Eaton Bussmann

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: NON-25
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : NON Series
• Type : NON
• Voltage : 250
• Amperage : 25
• AIC rating : 50kA@250V
• Diameter : 0.56
• Class Rating : K5
• Barrels : 1

Product Data

• UPC : 051712101585
• GTIN : 00051712101585
• Country of Origin : Mexico
• Dimensions : 2 in x 0.56 in x 0.56 in (Length/Depth x Height x Width)
• Weight : 0.35
• Certification : CE, UL Listed, Guide JDDZ, File E4274, STD 248-9, CSA Certified Class 1421-01, File 53787
