NON-10 - Eaton Bussmann Series NON 10A 250VAC 125VDC Class K5 General Purpose Non-Current-Limiting Fuse, Ferrule End, 50kA Interrupt Rating, UL/CSA/CE Certified

NON-10

NON-10 is a general purpose, non-current-limiting fuse from the Eaton Bussmann Series, designed for reliable circuit protection in a wide range of applications.

This one-time fuse features a 10A amperage rating, 250VAC and 125VDC voltage ratings, and a high interrupting rating of 50kA at both 250VAC and 125VDC. It is UL Listed (Class K5, Std. 248-9), CSA Certified (Class 1421-01), and CE Marked, ensuring compliance with international safety standards. The NON-10 is constructed with ferrule ends for secure mounting and is non-indicating, requiring visual inspection to confirm operation.

Key Specifications
• Part Number: NON-10
• Manufacturer: Eaton Bussmann
• Amperage: 10A
• Voltage: 250VAC, 125VDC
• Poles: Single
• Mounting Type: Ferrule end
• Interrupt Rating: 50kA at 250VAC, 50kA at 125VDC
• Series/Frame: NON, Class K5 (0-60A)
• Trip Unit: Non-current-limiting, one-time fuse
• Certifications: UL Listed, CSA Certified, CE Marked
• Packaging: Standard
• Dimensions: 2" x 0.56" x 0.56"

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: NON-10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : NON Series
• Type : NON
• Voltage : 250
• Amperage : 10
• AIC rating : 50kA@250V
• Diameter : 0.56
• Class Rating : K5
• Barrels : 1

Product Data

• UPC : 051712101554
• GTIN : 00051712101554
• Country of Origin : Mexico
• Dimensions : 2 in x 0.56 in x 0.56 in (Length/Depth x Height x Width)
• Weight : 0.25
• Certification : CE, UL Listed, Guide JDDZ, File E4274, STD 248-9, CSA Certified Class 1421-01, File 53787
