NON-1 - Eaton 1 Amp 250 Vac Class K5 General Purpose Fuse 50kA Interrupt Rating

NON-1

NON-1 is an Eaton Bussmann series Class K5 general purpose fuse rated for 1 amp at 250 Vac with a 50 kA interrupting rating.NON-1 is a non-current-limiting, one-time fuse designed for low voltage circuit protection. It features a cylindrical body with ferrule end connections and is CE marked for compliance. This fuse is suitable for general purpose applications requiring reliable overcurrent protection with a voltage rating of 250 Vac and 125 Vdc.

• Amperage Rating: 1 A
• Voltage Rating: 250 Vac, 125 Vdc
• Interrupt Rating: 50 kA at 250 Vac and 125 Vdc
• Class: K5
• Fuse Type: Non-current-limiting, one-time fuse
• Connection Type: Ferrule end x ferrule end
• Body Size: 0.56 in diameter x 2 in length
• Indicating: Non-indicating
• Compliance: CE Marked
• Mounting Type: Inline fuse holder compatible

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: NON-1
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : NON Series
• Type : NON
• Voltage : 250
• Amperage : 1
• AIC rating : 50kA@250V
• Diameter : 0.56
• Class Rating : K5
• Barrels : 1

Product Data

• UPC : 051712300018
• GTIN : 00051712300018
• Country of Origin : Mexico
• Dimensions : 0.56 in x 2 in x 0.56 in (Length/Depth x Height x Width)
• Weight : 0.35
• Certification : CE, UL Listed, Guide JDDZ, File E4274, STD 248-9, CSA Certified Class 1421-01, File 53787
