NON-1-1/2 - Bussmann, Cooper Bussmann, Eaton 1.5A 250V AC Class K5 One-Time Fuse, 0.56" x 2", 50kA Interrupt, UL/CSA Certified, General Purpose

NON-1-1/2

NON-1-1/2 is a Bussmann, Cooper Bussmann, and Eaton 1.5A 250V AC general purpose, one-time fuse designed for reliable circuit protection in a wide range of applications.

This Class K5 fuse features a compact 0.56" x 2" physical size, a 250V AC / 125V DC voltage rating, and a high interrupting rating of 50,000 amps. It is suitable for replacing existing Class H fuses and is certified to UL and CSA standards for safety and compliance.

Key Specifications
• Amperage: 1.5A
• Voltage: 250V AC, 125V DC
• Poles: Single
• Mounting Type: Ferrule (blade) ends
• Interrupt Rating: 50,000 AIC RMS @ 250V AC, 50,000 AIC @ 125V DC
• Series/Frame: Class K5 (0-60A), Std. 248-9 Class H (65-600A), Std. 248-6
• Trip Unit: One-time, non-renewable
• Certifications: UL Guide JDDZ (File E4274), CSA Certified (Class 1421-01, File 53787)
• Physical Size: 0.56" x 2"
• Application: General purpose branch circuit protection
• Replacement: Compatible with Class H, RK1, and RK5 fuse holders (dimensional)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: NON-1-1/2
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : NON Series
• Type : NON
• Voltage : 250
• Amperage : 1
• AIC rating : 50kA@250V
• Diameter : 0.56
• Class Rating : K5
• Barrels : 1

Product Data

• UPC : 051712300179
• GTIN : 00051712300179
• Country of Origin : Mexico
• Dimensions : 2 in x 0.56 in x 0.56 in (Length/Depth x Height x Width)
• Weight : 0.35
• Certification : CE, UL Listed, Guide JDDZ, File E4274, STD 248-9, CSA Certified Class 1421-01, File 53787
