Product Info
- Manufacturer: Littelfuse
- Sub-Category: Low Voltage Fuse
Description
NLS175
NLS175 is a Littelfuse Class K5 one-time fuse designed for industrial power protection.This fuse features a 175 ampere rating with a voltage rating of 600 VAC/VDC. It is a fast-acting, one-time use fuse with a knife-blade mounting style and an interrupting rating of 50,000 amperes at 600 VDC. The fuse is UL 248-9, CSA, and CE certified, ensuring compliance with key safety standards.
- Key Specifications
- Amperage: 175 Amps
- Voltage Rating: 600 VAC/VDC
- Fuse Class: Class K5
- Fuse Type: One-Time
- Speed: Fast-Acting
- Mounting Type: Knife-Blade
- Interrupting Rating: 50,000 Amperes at 600 VDC
- Certifications: UL 248-9, CSA, CE
- Diameter: 1-27/32 Inch
- Length: 9-5/8 Inch
- Part Number: NLS175
- Manufacturer : Littelfuse
- Brand : Littelfuse
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : NLS
- Type : NLS
- Voltage : 600
- Amperage : 175
- AIC rating : 50kA@600V
- Diameter : 3.09
- Class Rating : K5
- Barrels : 1
- UPC : 07945837087
- GTIN : 00079458370874
- Weight : 1.39 lb
