Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
NEB1B015B
NEB1B015B is a Siemens 1 pole molded case circuit breaker rated for 15 amps and 277 volts with bolt-on mounting.NEB1B015B features thermal magnetic trip unit with long-time and instantaneous trip functions, designed for reliable circuit protection in commercial and industrial applications. It has a 35kA interrupting rating at 277V and uses load side lug terminals for secure connections.
- Manufacturer: Siemens
- Part Number: NEB1B015B
- Amperage: 15 Amps
- Voltage Rating: 277 Volts AC
- Poles: 1
- Mounting Type: Bolt-On
- Interrupt Rating: 35kA at 277V
- Frame/Series: NEB
- Trip Unit: Thermal Magnetic with Long-Time and Instantaneous Functions
- Connection: Load Side Lug Terminals
- Phase: Single Phase
- Certifications: UL Listed
Specifications
- Part Number: NEB1B015B
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : NEB Series
- Type : NEB
- Voltage : 277
- Amperage : 15
- Phase : 1
- Poles : 1
- AIC rating : 35kA@277V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783643558144
- GTIN : 00783643558144
- Country of Origin : Dominican Republic
- Weight : 1.257
- Wire Size : AWS 8 to AWS 1/0, Cu/Al
