Product Info
- Manufacturer:Federal Pacific
- Sub-Category:Molded Case
Description
NB3P60
NB3P60 is a 60 Amp, 3 Pole thermal magnetic circuit breaker designed for bolt-on mounting in Federal Pacific electrical panels.This molded case circuit breaker operates at 240 Volts AC and features a thermal magnetic trip unit for reliable overcurrent protection. It is part of the NB series/frame and provides a breaking capacity of 10 kA. The breaker is CSA certified and uses screw connectors for electrical connections.
- Amperage: 60 A
- Voltage: 240 V AC
- Poles: 3
- Mounting Type: Bolt-On
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 10 kA
- Series/Frame: NB
- Electrical Connection: Screw Connector
- Certification: CSA
Specifications
- Part Number: NB3P60
- Manufacturer : Federal Pacific
- Brand : Federal Pacific
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : NB Series
- Type : NB
- Voltage : 240
- Amperage : 60
- Phase : 3
- Poles : 3
- AIC rating : 10kA@240V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Dimensions : Depth 5.38 in (136.65 mm) x Width 5.64 in (143.26 mm)
- Weight : 1
- Certification : CSA
- Wire Size : AWG 14...AWG 1/0 aluminum/copper
