MXD63S800A - Eaton Series C 800 A 3-Pole 600 V AC Molded Case Circuit Breaker, Type MXD6, Thermal-Magnetic Trip

MXD63S800A

MXD63S800A is a 3-pole molded case circuit breaker manufactured by Eaton as part of the Series C MXD6 Frame. It is rated for 800 A and up to 600 V AC, providing thermal-magnetic protection against overloads and short circuits in heavy-duty industrial and commercial applications. The MXD63S800A offers a high interrupting rating and a durable construction designed for demanding environments. It is compatible with a wide range of Eaton accessories, including auxiliary switches, shunt trips, and undervoltage releases, for flexible power distribution and control configurations.

• Part Number: MXD63S800A
• Manufacturer: Eaton
• Series / Frame: Series C / MXD6 Frame
• Product Type: Molded Case Circuit Breaker (MCCB)
• Poles: 3
• Amperage Rating: 800 A
• Voltage Rating: 600 V AC / 250 V DC
• Trip Unit Type: Fixed Thermal-Magnetic
• Interrupting Rating: Up to 65 kA at 480 V AC
• Frame Type: MXD6 (Series C)
• Mounting Type: Bolt-on or panel mount
• Application: Feeder and main protection in switchboards, panelboards, and MCCs
• Certifications: UL 489 Listed, CSA Certified, IEC 60947-2 Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Lugs are not included

Specifications

• Part Number: MXD63S800A
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : MXD
• Voltage : 600
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 50kA@480V
• Connection : Bolt-On
• Functions : NA - No Overcurrent Protection
• Frame Size : MD Frame
• Protection : Non-Automatic

Product Data

• UPC : 783643215337
• GTIN : 00783643215337
• Country of Origin : Mexico
• Weight : 53.7
• Certification : UL, CSA, NOM, IEC
