MP240240CT2 - Murray 40A 240V 2-Pole Plug-In Circuit Breaker MH Frame

MP240240CT2

MP240240CT2 is a Murray 40 Amp, 240 Volt, 2-Pole plug-in circuit breaker designed for reliable electrical protection.MP240240CT2 features a MH frame type with a common trip quadplex design, suitable for load centers requiring 10kA interrupt rating. It supports wire sizes from 14 to 8 AWG copper and 12 to 8 AWG aluminum on outside poles, and 8 to 4 AWG on inside poles. The breaker is HACR rated and UL 489 and CSA C22.2 certified for safety and performance.

Key Specifications
• Manufacturer: Murray
• Part Number: MP240240CT2
• Amperage: 40 Amps
• Voltage Rating: 120/240 VAC
• Number of Poles: 2
• Frame Type: MH
• Mounting Type: Plug-In
• Interrupt Rating: 10,000 Amps
• Trip Unit: Common Trip Quadplex
• Wire Size: 14-8 AWG Copper, 12-8 AWG Aluminum (Outside Poles)
• Certifications: UL 489, CSA C22.2

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: MP240240CT2
• Manufacturer : Murray
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : MP Series
• Type : MP-T
• Voltage : 240
• Amperage : 40
• Phase : 1
• Poles : 4
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : LI - Long-Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 040892001310
• GTIN : 00040892001310
• Country of Origin : Mexico
• Dimensions : 2.756 x 1.969 x 2.756 inch
• Weight : 0.794
• Wire Size : AWG 8 to AWG 6, Copper, AWG 8 to AWG 4, Aluminum
