2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Murray
- Sub-Category:Molded Case
Description
MP215
MP215 is a 15 Amp, 2 Pole, 120/240 Volt Type MP-T circuit breaker from Murray designed for reliable electrical protection.This thermal magnetic circuit breaker features a plug-in mounting type with a 10,000 A interrupting rating at 240V. It includes long time and instantaneous trip functions, load side lug terminals, and is suitable for single-phase applications. The MP frame ensures compatibility with Murray panelboards and load centers.
- Manufacturer: Murray
- Amperage: 15 Amp
- Voltage: 120/240 Volt AC
- Poles: 2 Pole
- Frame Type: MP
- Interrupt Rating: 10,000 A at 240V
- Mounting Type: Plug-In
- Trip Unit: Thermal Magnetic
- Phase: Single Phase
- Load Side Lug Terminals
- Non-Interchangeable Trip
- Type: MP-T
Specifications
- Part Number: MP215
- Manufacturer : Murray
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : MP Series
- Type : MP-T
- Voltage : 240
- Amperage : 15
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Plug-In
- Functions : LI - Long-Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 040892518931
- GTIN : 00040892518931
- Country of Origin : Mexico
- Dimensions : 5.906 x 2.756 x 1.969 inch
- Weight : 0.529
- Certification : Ul Listed
