Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage
Description
MIN-5
MIN-5 is a fast-acting, pin-indicating fuse designed for low voltage applications with a 5 ampere rating and 250 volts AC voltage rating.MIN-5 features a red pin for high visibility to indicate fuse opening and is UL listed and CSA certified for safety and reliability. It has a 100 amp interrupting rating at 250 VAC and is constructed with a fiber tube body and bronze ferrules plated with nickel. This 1-pole fuse is compatible with holder mounting styles and is part of Eaton's MIC/MIN series.
- Amperage: 5 A
- Voltage Rating: 250 VAC
- Fuse Type: Fast Acting
- Interrupt Rating: 100 AIC @ 250 VAC
- Poles: 1
- Mounting Type: Holder
- Body Material: Fiber Tube
- Ferrule Material: Bronze with Nickel Plating
- Pin Indicating: Red Pin for High Visibility
- Certifications: UL Listed (Guide JDYX, File E19180), CSA Certified (Class 1422-01, File 53787)
Specifications
- Part Number: MIN-5
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage
- Family : MIC Series
- Type : MIC
- Voltage : 250
- Amperage : 5
- AIC rating : 35kA@250V
- Diameter : 0.41
- Class Rating : Midget
- Barrels : 1
Product Data
- UPC : 05171272668
- Weight : 0.3
- Certification : Csa Certified Ce Marked
