2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage
Description
MIN-3
MIN-3 is a 3 amp, 250 VAC fast acting pin indicating midget fuse from Eaton designed for quick fuse opening indication.This Eaton MIN-3 fuse features a fiber tube body with bronze ferrules plated in nickel. It has a red pin for high visibility to indicate fuse operation. The fuse is UL listed to standard 248-14 and CSA certified, suitable for low voltage circuit protection with a 100A interrupt rating. It is part of the MIC/MIN series and designed for use in power electronic circuits requiring fast fuse operation and clear visual indication.
- Amperage: 3 Amp
- Voltage Rating: 250 VAC
- Fuse Type: Fast Acting
- Pin Indicating: Yes, red pin
- Interrupt Rating: 100 Amps
- Body Material: Fiber Tube
- Ferrule Material: Bronze with Nickel plating
- Series: MIC/MIN (5AG)
- Certifications: UL Listed, CSA Certified
- Mounting Type: Midget fuseholder compatible
Specifications
- Part Number: MIN-3
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage
- Family : MIC Series
- Type : MIC
- Voltage : 250
- Amperage : 3
- AIC rating : 35kA@250V
- Diameter : 0.41
- Class Rating : Midget
- Barrels : 1
Product Data
- UPC : 05171272667
- Weight : 0.3
