Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage
Description
MIN-15
MIN-15 is a 15 amp, 250 volt indicating fast-acting midget fuse from Eaton designed for quick visual identification of blown fuses.This Eaton MIN-15 fuse features a red indicating pin for high visibility upon fuse opening, fast-acting characteristics, and a cartridge mounting style. It has a 750 amp interrupt rating at 250 VAC and is UL listed to standard 248-14 and CSA certified. The fuse body is made of fiber tube with bronze ferrules plated in nickel. It measures approximately 1.5 inches in length and 0.41 inches in diameter.
- Key Specifications
- Amperage: 15 A
- Voltage Rating: 250 VAC
- Interrupt Rating: 750 AIC @ 250 VAC
- Fuse Type: Indicating, Fast-Acting
- Mounting Type: Cartridge
- Length: 1.5 inches (38.1 mm)
- Diameter: 0.41 inches (10.3 mm)
- Body Material: Fiber Tube
- Ferrule Material: Bronze with Nickel Plating
- Certifications: UL Listed, CSA Certified, CE Compliant
- Red Pin for Visual Indication
Specifications
- Part Number: MIN-15
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage
- Family : MIC Series
- Type : MIC
- Voltage : 250
- Amperage : 15
- AIC rating : 35kA@250V
- Diameter : 0.41
- Class Rating : Midget
- Barrels : 1
Product Data
- UPC : 051712726702
- GTIN : 00051712726702
- Weight : 3.5
- Certification : Ce Marked
