Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage
Description
MIN-10
MIN-10 is a fast-acting indicating fuse manufactured by Eaton designed for low voltage circuit protection.This Eaton MIN-10 fuse features a 10 ampere rating, 250 volts AC voltage rating, and a 1 pole configuration. It has a 200 amp interrupting rating (AIC) at 250 VAC and uses a fiber tube body with bronze ferrules plated in nickel. The fuse is UL listed and CSA certified, providing reliable and visible fuse operation with a red indicating pin for quick fault identification.
- Key Specifications
- Amperage: 10 Amps
- Voltage: 250 Volts AC
- Poles: 1
- Interrupt Rating: 200 Amps AIC @ 250 VAC
- Fuse Type: Fast-Acting Indicating
- Body Material: Fiber Tube
- Ferrule Material: Bronze with Nickel Plating
- Certifications: UL Listed, CSA Certified
- Mounting Type: Panel Mount (with compatible fuseholders)
- Series: MIC/MIN
Specifications
- Part Number: MIN-10
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage
- Family : MIC Series
- Type : MIC
- Voltage : 250
- Amperage : 10
- AIC rating : 35kA@250V
- Diameter : 0.41
- Class Rating : Midget
- Barrels : 1
Product Data
- UPC : 051712726696
- GTIN : 00051712726696
- Weight : 0.6
- Certification : Ce Marked
