MIC-5 - Eaton 5A 250V Fast-Acting Midget Fuse, Non-Indicating, 200AIC, Ferrule End x Ferrule End

MIC-5

MIC-5 is a fast-acting, 5 amp, 250 volt midget fuse from Eaton's Bussmann series designed for control and electronic circuits.This non-indicating fuse features a fiber tube body with nickel-plated bronze ferrule ends, providing a 200 amp interrupting rating at 250 VAC. It is suitable for use in power and control circuits requiring quick fuse operation and reliable protection.

• Amperage Rating: 5 A
• Voltage Rating: 250 V AC
• Interrupting Rating: 200 AIC at 250 VAC
• Fuse Type: Fast-Acting (Fast Blow)
• Connection: Ferrule End x Ferrule End
• Body Material: Fiber Tube
• Ferrule Material: Nickel-Plated Bronze
• Fuse Indicator: Non-Indicating
• Series: Eaton Bussmann MIC
• Certifications: CE Marked
• Dimensions: 13/32" x 1-1/2" (approx. 10.3 mm x 38.1 mm)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: MIC-5
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : MIC Series
• Type : MIC
• Voltage : 250
• Amperage : 5
• AIC rating : 200kA@250V
• Diameter : 0.41
• Class Rating : Midget
• Barrels : 1

Product Data

• UPC : 051712726450
• GTIN : 00051712726450
• Dimensions : 0.47 in x 1.813 in x 0.47 in (Length/Depth x Height x Width)
• Weight : 0.15
