- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
MIC-2
MIC-2 is a fast-acting midget fuse designed for reliable circuit protection in control, PLC, and electronic applications. This Eaton Bussmann series fuse features a 2A current rating and a 250V maximum voltage rating, making it suitable for a wide range of industrial and commercial uses. The MIC-2 fuse is constructed with a silver-plated pin for positive contact and dependable performance. It is non-indicating, meaning it does not provide a visual signal when blown. This fuse is UL Listed and meets CSA standards, ensuring compliance with safety requirements for electrical installations.
- Amperage Rating: 2A
- Voltage Rating: 250V AC
- Interrupt Rating: 100AIC at 250V AC
- Mounting Type: Pin
- Series/Frame: Bussmann MIC
- Fast-Acting
- Non-Indicating
- UL Listed
- CSA Certified
- For Control, PLC, and Electronic Circuits
Specifications
- Part Number: MIC-2
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : MIC Series
- Type : MIC
- Voltage : 250
- Amperage : 2
- AIC rating : 100kA@250V
- Diameter : 0.41
- Class Rating : Midget
- Barrels : 1
Product Data
- UPC : 051712726436
- GTIN : 00051712726436
- Dimensions : 0.47 in x 1.813 in x 0.47 in (Length/Depth x Height x Width)
- Weight : 0.15
- Certification : Ul Listed Ce Marked
