MGN61332 - Schneider Electric 20A 3-Pole Multi9 Molded Case Circuit Breaker 480Y/277V C Curve

Save $240.22
SKU: MGN61332-ReCert
Condition: Re-Certified
Price:
$278.78 $519.00
Stock:
Low inventory, please call for stock check
This ships in 1-2 business days

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

MGN61332 - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
MGN61332 - Essential Electric Supply

Description

MGN61332


MGN61332 is a 20 amp, 3-pole molded case circuit breaker from Schneider Electric's Multi9 family designed for reliable circuit protection in industrial and commercial applications.MGN61332 operates at 480Y/277 volts AC with a C curve trip characteristic, suitable for general-purpose protection. It features a rated insulation voltage of 500V AC and complies with EN/IEC 60947-2 standards. The breaker has an interrupting rating of 10kA at 480Y/277V and is designed for panel mounting with tunnel-type terminals.
    Key Specifications
    • Amperage: 20 A
    • Poles: 3
    • Voltage Rating: 480Y/277 V AC
    • Trip Curve: C Curve
    • Interrupt Rating: 10 kA
    • Series/Frame: Multi9 C60
    • Mounting Type: Panel Mount
    • Standards: EN/IEC 60947-2, UL489
    At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

    Specifications

    • Part Number: MGN61332
    • Manufacturer : Schneider Electric
    • Brand : Schneider Electric
    • Category : Circuit Breaker
    • Item Subcategory : Molded Case
    • Family : Multi9
    • Type : C60
    • Voltage : 480
    • Amperage : 20
    • Phase : 3
    • Poles : 3
    • AIC rating : 10kA@480V
    • Connection : Feed-Thru
    • Functions : LI - Long-Time and Instantaneous
    • Protection : Thermal Magnetic

    Product Data

    • UPC : 785901560937
    • GTIN : 785901560937
    • Dimensions : 5.6 in (141 mm) x 2.1 in (54 mm) x 2.7 in (68.7 mm) (Height x Width x Depth)
    • Weight : 1.09
    • Certification : UL, CSA, IEC, CCC
