Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
MEQ2
MEQ2 is an Eaton Edison MEQ fuse designed for supplemental protection of transformers, solenoids, and high inrush power electronic circuits.MEQ2 features a 2 ampere rating, 500 volt AC voltage rating, and a 10 kA interrupting rating with fiber tube construction. This time-delay, dual-element current limiting fuse is non-indicating and UL Listed and CSA Certified for safety and reliability.
- Amperage Rating: 2 A
- Voltage Rating: 500 V AC
- Interrupting Rating: 10 kAIC
- Fuse Type: Time Delay, Dual Element
- Construction: Fiber Tube
- Fuse Indicator: Non-indicating
- Certifications: UL Listed, CSA Certified
- Application: Supplemental protection for transformers and high inrush circuits
- Mounting Type: Rejection Style
- Series: Eaton Edison MEQ
Specifications
- Part Number: MEQ2
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : MEQ Series
- Type : MEQ
- Voltage : 500
- Amperage : 2
- AIC rating : 10kA@500V
- Diameter : 0.41
- Class Rating : Midget
- Barrels : 1
Product Data
- UPC : 782634786023
- GTIN : 00782634786023
- Dimensions : 1 in x 0.406 in x 0.406 in (Length/Depth x Height x Width)
- Weight : 0.2
