Product Info
- Manufacturer:Edison Fuses
- Sub-Category:Low Voltage Fuse
Description
MEN2.8
MEN2.8 is a 2.8 amp, 250 volt time-delay midget fuse designed for general purpose circuit protection.MEN2.8 offers reliable supplemental protection for small motors, transformers, solenoids, and electronic circuits with high inrush currents. It features a 10,000 RMS amp interrupt rating at 125 VAC and is UL listed, CSA certified, and CE compliant.
- Amperage: 2.8 A
- Voltage Rating: 250 VAC
- Fuse Type: Time-Delay (Midget)
- Interrupt Rating: 10,000 RMS Amps @ 125 VAC
- Mounting Type: Ferrule End X Ferrule End
- Non-indicating fuse
- Agency Approvals: UL Listed, CSA Certified, CE Compliant
- Series: MEN General Purpose Midget Class
- Application: Supplemental protection for small motors and transformers
Specifications
- Part Number: MEN2.8
- Manufacturer : Edison Fuses
- Brand : Edison Fuses
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Voltage : 250
- Amperage : 2.8
- AIC rating : 10kA@125V
- Diameter : 0.41
- Class Rating : Midget
- Barrels : 1
Product Data
- UPC : 78263452023
- GTIN : 00782634520238
- Dimensions : 1 in x 0.406 in x 0.406 in (Length/Depth x Height x Width)
- Weight : 0.001
