Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
MAL365001027
MAL365001027 is a Square D 3-pole molded case circuit breaker designed for panel mount feed-thru applications with a 500 Amp rating and 600 VAC voltage capacity.This thermal magnetic circuit breaker features a fixed trip unit, M frame style, and a 30kA interrupting rating at 480 VAC. It is UL and CSA certified, suitable for industrial and commercial power distribution systems requiring reliable overcurrent protection. The breaker supports lug-to-lug or feed-thru mounting and complies with applicable electrical standards.
- Key Specifications
- Amperage: 500 Amp
- Voltage: 600 VAC
- Poles: 3
- Mounting Type: Panel Mount Feed-Thru
- Interrupting Rating: 30kA @ 480 VAC
- Frame/Series: M Frame
- Trip Unit: Thermal Magnetic Fixed Trip
- Certifications: UL Listed, CSA Certified
- Style: Molded Case Circuit Breaker
- Brand: Square D
Additional Information
complete with 24Vdc shunt trip
Specifications
- Part Number: MAL365001027
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 600
- Amperage : 500
- Phase : 3
- Poles : 3
- AIC rating : 30kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Weight : 40
