Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
LXD63B450H
LXD63B450H - Siemens Sentron series molded case circuit breaker, 450A, 3 pole, 600VAC, thermal magnetic trip.
This bolt-on circuit breaker features a LXD frame, long time, short time, and instantaneous trip functions, 100% rated draw, non-interchangeable trip unit, and is suitable for reverse fed applications with load side lug terminals.
Key Specifications
- Amperage: 450A
- Voltage: 600VAC
- Poles: 3
- Mounting Type: Bolt-On
- Frame: LXD
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 35kA@480V
- 100% Rated
- Non-Interchangeable Trip
- Suitable for Reverse Fed
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: LXD63B450H
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : LXD
- Voltage : 600
- Amperage : 450
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : Non-Interchangeable
- Frame Size : LD Frame
- Temp Rating : -13¡F-158¡F
- Protection : Thermal Magnetic
Product Data
- UPC : 783643011144
- GTIN : 00783643011144
- Country of Origin : Mexico
- Dimensions : 8.661 x 12.992 x 6.702
- Weight : 17.8
- Certification : Ul Listed
