LX1FF092 - Square D 110 VAC 60 Hz TeSys F Contactor Coil for LC1F150 LCF115 Series Motor Control

LX1FF092

LX1FF092 is a Square D TeSys F contactor coil designed for motor control applications requiring 110 VAC at 60 Hz.

This coil is compatible with LC1F150 and LCF115 series contactors, featuring a control circuit voltage of 110 V AC 60 Hz, an inductance of 0.59 H, and an average resistance of 4.55 Ohm at 20 °C. It offers mechanical durability up to 10 million cycles and a maximum operating rate of 2400 cycles per hour at 131°F (55°C). This coil is engineered for reliable performance in industrial motor control systems.

• Voltage: 110 VAC, 60 Hz
• Compatible with LC1F150 and LCF115 series contactors
• Control circuit type: AC
• Inductance: 0.59 H
• Average resistance: 4.55 Ohm at 20 °C
• Mechanical durability: 10 million cycles
• Maximum operating rate: 2400 cycles/hour at 131°F (55°C)
• Heat dissipation: 12–16 W at 60 Hz
• Operating temperature range: -5 to 55 °C
• Type: Contactor coil

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LX1FF092
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Motor Control
• Item Subcategory : Magnetic Coil
• Voltage : 110
• Amperage : 2000
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Solid State

Product Data

• Weight : 1.038
