LV430404 - Schneider Electric Compact NSX160H Circuit Breaker 160A 3 Poles 70kA 415VAC Without Trip Unit

LV430404

LV430404 is a Schneider Electric Compact NSX160H circuit breaker basic frame designed for 160A current and 3 poles without a trip unit.This circuit breaker features a 70kA interrupt rating at 415VAC 50/60 Hz and complies with IEC 60947 standards along with CCC, EAC, and marine certifications. It has a lug connection type with downside front connection and mechanical durability rated for 40,000 cycles. The device dimensions are 105mm x 161mm x 86mm, suitable for various industrial applications.

• Amperage: 160A
• Voltage Rating: 415VAC (70kA interrupt rating), operational voltage up to 690V AC
• Poles: 3
• Mounting Type: Basic frame with lug connection, downside front connection
• Interrupt Rating: 70kA at 415VAC
• Series/Frame: Compact NSX160H
• Trip Unit: Without trip unit
• Certifications: IEC 60947, CCC, EAC, Marine specifications
• Mechanical Durability: 40,000 cycles
• Dimensions: 105mm x 161mm x 86mm

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item is Frame only as definded by the part number. That means it is only the circuit breaker frame, and no lugs or trip unit is included with the frame.

Specifications

• Part Number: LV430404
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Compact NSX
• Type : LV4
• Voltage : 690
• Amperage : 160
• Phase : 3
• Poles : 3
• AIC rating : 70kA@415V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 785901067849
• GTIN : 03606480006661
• Country of Origin : Poland
• Dimensions : Depth 27.00 in (68.58 cm) Width 24.00 in (60.96 cm) Height 47.00 in (119.38 cm)
• Weight : 3.298
• Standards : EN/IEC 60947-2, UL 508
