LR9D69 - Telemecanique TeSys D Electronic Thermal Overload Relay 90-150A Class 10-20

LR9D69

LR9D69 is an electronic thermal overload relay from the TeSys D series, designed for reliable motor protection in industrial applications. This device provides adjustable overload protection for motors with a thermal range of 90 to 150 amps and offers selectable tripping class 10 to 20 for flexible motor control. The LR9D69 features advanced electronic monitoring for unbalanced loads and is compatible with a wide range of motor starter configurations. It is engineered for durability and precise protection, supporting motor loads from 55 to 75kW at 400V. The relay is designed for easy integration into standard control panels and offers dependable performance in demanding environments.

• Part Number: LR9D69
• Manufacturer: Telemecanique
• Series: TeSys D
• Thermal Range: 90-150A
• Tripping Class: 10-20 (selectable)
• Motor Protection: 55-75kW @ 400V
• Mounting Type: Panel mount
• Operating Temperature: -20 to 60°C
• Compliance: IEC 60947-4-1
• Power Circuit Voltage: 1000V
• Coil Voltage: 24 V DC
• Application: Motor overload protection

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LR9D69
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Motor Control
• Item Subcategory : Overload Relay
• Family : TeSys D
• Type : LR9D
• Relay Style : Thermal
• Amperage Maximum : 150
• Amperage Minimum : 90
• Compatible Frames : TJS,TJSS,TKS,THKS,THKSS,TPSS,THPSS

Product Data

• UPC : 060648533579
• GTIN : 03606485335797
• Country of Origin : France
• Dimensions : 4.6 in (118 mm) x 4.5 in (115 mm) x 4.9 in (125 mm) (Height x Width x Depth)
• Weight : 1.993
• Certification : EN/IEC 60947-4-1, EN/IEC 60947-5-1, UL 60947-4-1, UL 60947-5-1, CSA C22.2 No 60947-4-1, CSA C22.2 No 60947-5-1, GB/T 14048.4, GB/T 14048.5
