LPS-RK-5SP - Eaton Bussmann 5A 600Vac/300Vdc Time Delay Dual Element Class RK1 Fuse

LPS-RK-5SP

LPS-RK-5SP is a 5 amp, time-delay, dual-element, current-limiting Class RK1 fuse from Eaton Bussmann series designed for reliable circuit protection.This fuse features a voltage rating of 600 Vac and 300 Vdc, with an interrupting rating of 300 kA at 600 Vac and 100 kA at 300 Vdc. It has a non-indicating ferrule end connection and provides a 10 second time delay at 500% overload, making it suitable for protecting motors and other inductive loads. The fuse is electrically isolated at the end cap and CE marked for compliance.

Key Specifications
• Amperage: 5 A
• Voltage Rating: 600 Vac / 300 Vdc
• Interrupt Rating: 300 kA at 600 Vac, 100 kA at 300 Vdc
• Fuse Type: Time Delay, Dual Element, Current Limiting
• Class: RK1
• Connection: Ferrule end x ferrule end
• Fuse Indicator: Non-indicating
• Dimensions: 0.81 in diameter x 5 in length
• Compliance: CE Marked
• Special Features: Electrically isolated end cap

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LPS-RK-5SP
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Low-Peak
• Type : LPS-RK
• Voltage : 600
• Amperage : 5
• AIC rating : 300kA@600V
• Diameter : 0.81
• Class Rating : RK1
• Barrels : 1

Product Data

• UPC : 051712548236
• GTIN : 00051712548236
• Country of Origin : Mexico
• Dimensions : 5 in x 0.81 in x 0.81 in (Length/Depth x Height x Width)
• Weight : 1.6
• Certification : CE, UL Special Purpose Guide JFHR, Guide JDDZ, File E4273, CSA Class 1422-02, File 53787, CSA C22.2, No. 248.12
