LPS-RK-35SP - Eaton Bussmann 35A 600V AC 300V DC Class RK1 Time Delay Fuse

LPS-RK-35SP

This fuse features a non-indicating design with ferrule end connections, providing high interrupting ratings of 300 kA at 600 VAC and 100 kA at 300 VDC. It offers time-delay protection with a response time of 10 seconds at 500% overload, suitable for motor and circuit protection. The fuse is CE marked and UL listed, ensuring compliance with industry standards.

Key Specifications
• Amperage: 35 A
• Voltage Rating: 600 VAC, 300 VDC
• Interrupting Rating: 300 kA at 600 VAC, 100 kA at 300 VDC
• Fuse Type: Time Delay, Dual Element, Current Limiting
• Class: RK1
• Connection: Ferrule end x ferrule end
• Fuse Indicator: Non-indicating
• Response Time: 10 seconds at 500% overload
• Dimensions: 1.06 in diameter x 5.5 in length
• Certifications: UL Listed, CSA Certified, CE Marked
• Special Features: Electrically isolated end cap

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.




Specifications

• Part Number: LPS-RK-35SP
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Low-Peak
• Type : LPS-RK
• Voltage : 600
• Amperage : 35
• AIC rating : 300kA@600V
• Diameter : 1.06
• Class Rating : RK1
• Barrels : 1



Product Data

• UPC : 051712548373
• GTIN : 00051712548373
• Country of Origin : Mexico
• Dimensions : 5.5 in x 1.06 in x 1.06 in (Length/Depth x Height x Width)
• Weight : 2.6
• Certification : CE, UL Special Purpose Guide JFHR, Guide JDDZ, File E4273, CSA Class 1422-02, File 53787, CSA C22.2, No. 248.12
