LPS-RK-17-1/2SP - Eaton Bussmann 17.5A 600VAC 300VDC Class RK1 Time Delay Fuse

LPS-RK-17-1/2SP

LPS-RK-17-1/2SP is a Bussmann Eaton Class RK1 time delay fuse rated for 17.5 amps and designed for high performance in power distribution applications.This fuse features a dual-element, current-limiting design with a 600 VAC and 300 VDC voltage rating, providing reliable protection with a 300 kA interrupting rating. It is non-indicating and has a cylindrical melamine body with ferrule end terminals for cartridge holder mounting. The fuse offers a time-delay response of approximately 8 to 10 seconds at 500% rated current, suitable for motor and transformer protection.

Key Specifications
• Amperage: 17.5 A
• Voltage Rating AC: 600 VAC
• Voltage Rating DC: 300 VDC
• Interrupt Rating: 300 kA AC / 100 kA DC
• Class: RK1
• Fuse Type: Time Delay, Dual Element
• Mounting Type: Cartridge Holder
• Body Type: Cylindrical Melamine
• Terminal Type: Ferrule End
• Indicating: Non-Indicating
• Response Time: 8-10 seconds at 500% rated current
• Series: LPS-RK

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LPS-RK-17-1/2SP
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Low-Peak
• Type : LPS-RK
• Voltage : 600
• Amperage : 17
• AIC rating : 300kA@600V
• Diameter : 0.81
• Class Rating : RK1
• Barrels : 1

Product Data

• UPC : 051712548335
• GTIN : 00051712548335
• Country of Origin : Mexico
• Dimensions : 5 in x 0.81 in x 0.81 in (Length/Depth x Height x Width)
• Weight : 0.17
• Certification : CE, UL Special Purpose Guide JFHR, Guide JDDZ, File E4273, CSA Class 1422-02, File 53787, CSA C22.2, No. 248.12
