LPN-RK-1SP - Eaton Bussmann Class RK1 Time-Delay Dual-Element 1A 250Vac/125Vdc Fuse

LPNRK1SP

LPN-RK-1SP is an Eaton Bussmann Series Class RK1 time-delay, dual-element, current-limiting fuse rated 1 ampere at 250 Vac and 125 Vdc.

This non-indicating fuse delivers high interrupting capacity with 300 kA at 250 Vac and 100 kA at 125 Vdc, making it ideal for motor protection, feeder circuits, transformers, and general-purpose applications. The dual-element design provides time-delay protection with an 8-second response at 500% rated current, protecting against single-phase motor damage while allowing 130% FLA sizing for backup motor protection. Current-limiting technology reduces destructive thermal and magnetic forces during short-circuit events, with no venting of arc or molten metal. Ferrule-end connections ensure secure installation in standard fuse holders.

Key Specifications

• Amperage Rating: 1 A
• Voltage Rating: 250 Vac, 125 Vdc
• Interrupt Rating: 300 kAIC at 250 Vac, 100 kAIC at 125 Vdc
• Fuse Type: Time-delay, current-limiting
• Class: RK1
• Number of Elements: Dual
• Response Time: 8 seconds at 500% rated current
• Connection: Ferrule end x ferrule end
• Fuse Indicator: Non-indicating
• Physical Dimensions: 2 in length x 0.56 in height x 0.56 in width
• Certifications: cULus Listed, CE Marked
• Packaging Quantity: 10 per box

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LPNRK1SP
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage
• Family : Low-Peak
• Voltage : 250
• Amperage : 1
• AIC rating : 300kA@250V
• Diameter : 0.56
• Class Rating : RK1
• Barrels : 1

Product Data

• Weight : 25
