LPN-RK-3-1/2SP - Eaton 3.5A Class RK1 Dual Element Time-Delay Fuse 250VAC/DC Non-Indicating

LPN-RK-3-1/2SP

LPN-RK-3-1/2SP is a Class RK1 dual element, time-delay, current-limiting fuse designed for reliable circuit protection in industrial and commercial applications. This Eaton Bussmann series fuse features a non-indicating design and is rated for 3.5A at 250VAC and 250VDC, providing robust protection against overloads and short circuits. Engineered for superior electrical safety, the LPN-RK-3-1/2SP fuse offers a 300 kAIC interrupt rating at 250VAC and 100 kAIC at 250VDC. Its dual element construction ensures time-delay performance, making it ideal for applications requiring both overload and short-circuit protection. The fuse is electrically isolated with blade end connections and is CE marked and RoHS compliant for global compatibility.

• Amperage Rating: 3.5 A
• Voltage Rating: 250 Vac, 250 Vdc
• Interrupt Rating: 300 kAIC at 250 Vac, 100 kAIC at 250 Vdc
• Fuse Type: Time-delay, current-limiting
• Number of Elements: Dual
• Class: Class RK1
• Connection Type: Blade end x blade end
• Fuse Indicator: Non-indicating
• Mounting Type: Standard fuse holder
• Series: Eaton Bussmann LPN-RK
• Certifications: CE Marked, RoHS Compliant
• Agency Listings: UL 248-12, CSA C22.2 No. 248.12

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LPN-RK-3-1/2SP
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Low-Peak
• Type : LPN-RK
• Voltage : 250
• Amperage : 3
• AIC rating : 300kA@250V
• Diameter : 0.56
• Class Rating : RK1
• Barrels : 1

Product Data

• UPC : 051712538206
• GTIN : 00051712538206
• Country of Origin : Mexico
• Dimensions : 2 in x 0.6 in x 0.6 in (Length/Depth x Height x Width)
• Weight : 0.049
• Certification : CE, UL Special Purpose Guide JFHR, Guide JDDZ, File E4273, CSA Class 1422-02, File 53787, CSA C22.2, No. 248.12
