Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
LPJ-225SP
LPJ-225SP is a Class J, time-delay, current-limiting fuse from Eaton Bussmann, designed for reliable circuit protection in demanding electrical applications.
This dual-element, non-indicating fuse offers fast short-circuit protection and time-delay performance, minimizing nuisance trips during motor starts and inrush currents. It features a high interrupting rating and is suitable for a wide range of industrial and commercial uses.
-
Key Specifications
- Amperage: 225 Amp
- Voltage: 600V AC
- Poles: Not specified (fuse, not a breaker)
- Mounting Type: Bolted blade end x bolted blade end
- Interrupt Rating: 300,000 A (300kAIC)
- Series/Frame: LPJ (Class J)
- Trip Unit: Dual element, time-delay (10 seconds minimum at 500% rating)
- Certifications: UL Listed (Class J)
- Physical Size: 2.11" x 7.126"
- Current-Limiting: Yes
- Non-Indicating: Yes
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: LPJ-225SP
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Low-Peak
- Type : LPJ
- Voltage : 600
- Amperage : 225
- AIC rating : 300kA@600V
- Diameter : 2.11
- Class Rating : J
- Barrels : 1
Product Data
- UPC : 051712523196
- GTIN : 00051712523196
- Country of Origin : Mexico
- Dimensions : 7.13 in x 2 in x 2 in (Length/Depth x Height x Width)
- Weight : 1.5
- Certification : CE/UL-Special Purpose Guide JFHR/CSA Class 1422-02
