LP-CC-8/10 - Eaton Bussmann Class CC Time-Delay Current-Limiting Fuse 8A 600V Rejection Style

LP-CC-8/10

LP-CC-8/10 is an Eaton Bussmann Class CC time-delay, current-limiting fuse designed for specialized circuit protection.This fuse features an 8 ampere rating with a voltage rating of 600 Vac and 300 Vdc, dual-element construction for time-delay performance, and a rejection style tip to prevent installation in incorrect fuse holders. It has a high interrupting rating of 200,000 AIC at 600 Vac and 20,000 AIC at 150 Vdc, making it suitable for small horsepower motor circuits and industrial control applications. The fuse is UL Listed, CSA Certified, and CE marked, ensuring compliance with industry standards.

• Amperage: 8 A
• Voltage Rating: 600 Vac, 300 Vdc
• Class: CC
• Time-Delay: Minimum 12 seconds at 200% rated current
• Interrupt Rating: 200 kA at 600 Vac, 20 kA at 150 Vdc
• Dual-element current limiting
• Rejection style fuse
• Non-indicating
• Dimensions: 0.41" x 1.5"
• Certifications: UL Listed, CSA Certified, CE Marked
• Application: Small horsepower motor circuits, industrial control

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LP-CC-8/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Medium Voltage Fuse
• Family : Low-Peak
• Type : LP-CC
• Voltage : 600
• Amperage : 8
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 051712180429
• GTIN : 00051712180429
• Country of Origin : Mexico
• Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.15
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
