LP-CC-6/10 - Bussmann Class CC 6/10A 600V Time Delay Fuse, Dual Element, Rejection Type, 0.41" x 1.5"

LP-CC-6/10

LP-CC-6/10 is a Bussmann Class CC time delay fuse designed for reliable circuit protection in small horsepower motor applications. This dual element, current-limiting fuse features a rejection style body and provides superior protection with a 12-second minimum time delay at 200% rated current. Suitable for use in 600V AC and 300V DC circuits, it offers an interrupting rating of 200,000 AIC RMS at 600VAC and 20,000 AIC at 300VDC. The LP-CC-6/10 is UL Listed, CSA Certified, and meets UL 248-4 standards for safety and performance.

• Part Number: LP-CC-6/10
• Manufacturer: Bussmann, Cooper Bussmann, Eaton
• Amperage: 6/10A
• Voltage Rating: 600V AC, 300V DC
• Class: CC
• Type: Time Delay, Dual Element, Current Limiting
• Interrupting Rating: 200,000 AIC RMS @ 600VAC, 20,000 AIC @ 300VDC
• Mounting Type: Ferrule End
• Physical Size: 0.41" x 1.5"
• Series: LP-CC
• Approvals: UL Listed, CSA Certified
• Application: Small Horsepower Motor Circuits

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LP-CC-6/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Medium Voltage Fuse
• Family : Low-Peak
• Type : LP-CC
• Voltage : 600
• Amperage : 6
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 051712180412
• GTIN : 00051712180412
• Country of Origin : Mexico
• Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.15
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
