LP-CC-5-6/10 - Eaton Bussmann 5.6A 600V Class CC Time Delay Fuse

LP-CC-5-6/10

LP-CC-5-6/10 is a 5.6 amp, 600 volt Class CC time delay fuse from Eaton Bussmann designed for small horsepower motor circuit protection.This fuse features a dual-element, time-delay design with a minimum 12-second delay at 200% rated current, providing reliable protection and selective coordination. It has a 200,000 AIC interrupt rating at 600 VAC and 20,000 AIC at 150 VDC. The fuse is UL Listed, CSA Certified, and meets Class 1422-02 standards. Its compact size measures 0.41" diameter by 1.5" length and includes a rejection feature to prevent incorrect fuse replacement.

Key Specifications
• Amperage: 5.6 A
• Voltage Rating: 600 VAC, 150 VDC
• Fuse Class: Class CC
• Time Delay: Minimum 12 seconds at 200% rated current
• Interrupt Rating: 200,000 AIC at 600 VAC, 20,000 AIC at 150 VDC
• Dual Element Construction
• Physical Size: 0.41" diameter x 1.5" length
• Rejection Type Fuse
• Certifications: UL Listed, CSA Certified, Class 1422-02
• Typical Use: Small horsepower motor circuit protection
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: LP-CC-5-6/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Low-Peak
• Type : LP-CC
• Voltage : 600
• Amperage : 5
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1



Product Data

• UPC : 051712180511
• GTIN : 00051712180511
• Country of Origin : Mexico
• Dimensions : 0.41 in x 1.5 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.15
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
