Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
LP-CC-4-1/2
LP-CC-4-1/2 is a 4.5 amp, 600 volt AC Class CC time-delay fuse from Eaton Bussmann designed for reliable circuit protection.This Low-Peak LP-CC series fuse features current-limiting and time-delay characteristics with a 12-second delay at 200% rated current. It has a 200kA interrupt rating at 600V AC and 20kA at 150V DC, a melamine cylindrical body, and is a rejection-type fuse to prevent misapplication. The fuse is non-indicating and dual-element for enhanced protection in specialized circuits.
- Amperage: 4.5A
- Voltage Rating: 600V AC / 150V DC
- Class: CC
- Fuse Type: Time-Delay, Current-Limiting
- Interrupt Rating: 200kA AC / 20kA DC
- Body Material: Melamine
- Body Style: Cylindrical
- Length: 1.5 inches
- Diameter: 13/32 inches
- Rejection Type: Yes
- Indicating: Non-Indicating
- Series: LP-CC
Specifications
- Part Number: LP-CC-4-1/2
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Low-Peak
- Type : LP-CC
- Voltage : 600
- Amperage : 4
- AIC rating : 200kA@600V
- Diameter : 0.41
- Class Rating : CC
- Barrels : 1
Product Data
- UPC : 051712180368
- GTIN : 00051712180368
- Country of Origin : Mexico
- Dimensions : 0.41 in x 1.5 in x 0.41 in (Length/Depth x Height x Width)
- Weight : 0.15
- Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
