LP-CC-3-2/10 - Bussmann Eaton 3.2A 600VAC/150VDC Class CC Time Delay Fuse 200kA Interrupt

LP-CC-3-2/10

LP-CC-3-2/10 is a Bussmann Eaton Class CC time delay fuse designed for reliable circuit protection.This 3.2 amp fuse features a dual-element, current-limiting design with a 12-second time delay at 200% rated current. It is rated for 600 VAC and 150 VDC operation with a high interrupting rating of 200 kA at AC and 20 kA at DC. The fuse has a cartridge body type with ferrule terminals and is intended for holder mounting. It is a rejection style fuse ensuring proper application and safety compliance. The body is made of melamine and the fuse meets UL, CSA, and CE certifications.

Key Specifications
• Amperage: 3.2 A
• Voltage Rating: 600 VAC / 150 VDC
• Interrupt Rating: 200 kA AC / 20 kA DC
• Class: CC
• Time Delay: 12 seconds at 200% rated current
• Body Type: Cartridge
• Mounting Type: Holder
• Terminal Type: Ferrule
• Series: LP-CC Low-Peak
• Rejection Style: Yes
• Material: Melamine
• Certifications: UL Listed, CSA Certified, CE Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LP-CC-3-2/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Low-Peak
• Type : LP-CC
• Voltage : 600
• Amperage : 3
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 051712180351
• GTIN : 00051712180351
• Country of Origin : Mexico
• Dimensions : 0.41 in x 1.5 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.15
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
