LP-CC-3-1/2 - Bussmann, Cooper Bussmann, Eaton 3.5A 600VAC/300VDC Class CC Time-Delay Current-Limiting Fuse, Rejection Style, Dual Element, 200kA Interrupt Rating, UL Listed, CSA Certified

LP-CC-3-1/2

LP-CC-3-1/2 is a Bussmann, Cooper Bussmann, and Eaton 3.5 amp, 600VAC/300VDC, Class CC, time-delay, current-limiting fuse designed for specialized circuits and industrial control applications.

This rejection-style, dual-element fuse offers a 200,000 AIC interrupting rating at 600VAC and 20,000 AIC at 300VDC, with a 12-second minimum time delay at 200% of rated current. The LP-CC-3-1/2 is non-indicating, features ferrule ends, and is housed in a melamine tube. It is ideal for protecting small horsepower motor circuits and provides high short-circuit protection with a compact 0.41" x 1.5" footprint.

Key Specifications
• Amperage: 3.5A
• Voltage: 600VAC, 300VDC
• Poles: Single
• Mounting Type: Ferrule end x ferrule end
• Interrupt Rating: 200,000 AIC @ 600VAC, 20,000 AIC @ 300VDC
• Series/Frame: LP-CC (Low-Peak™)
• Trip Unit: Time-delay, dual element
• Certifications: UL Listed, CSA Certified, CE Marked, RoHS Compliant
• Response Time: 12 seconds minimum at 200% rated current
• Fuse Indicator: Non-indicating
• Physical Size: 0.41" x 1.5"
• Application: Specialized circuits, industrial controls, small motor protection

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LP-CC-3-1/2
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Low-Peak
• Type : LP-CC
• Voltage : 600
• Amperage : 3
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 005171218030
• GTIN : 00051712180306
• Country of Origin : Mexico
• Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.15
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
