LP-CC-20 - Eaton Bussmann 20A 600V Class CC Time-Delay Current-Limiting Fuse

LP-CC-20

LP-CC-20 is a 20 amp, 600 volt Class CC time-delay current-limiting fuse from Eaton Bussmann series designed for specialized circuit protection.This dual-element, rejection style fuse features a 12-second minimum time delay at 200% rated current, an interrupt rating of 200 kA at 600 Vac and 20 kA at 300 Vdc, and a melamine tube construction. It is UL Listed, CSA Certified, CE marked, and RoHS compliant, suitable for protecting small horsepower motor circuits and industrial control applications.

• Amperage: 20 A
• Voltage Rating: 600 Vac, 300 Vdc
• Class: CC
• Fuse Type: Time-delay, dual-element, current-limiting
• Interrupt Rating: 200 kA at 600 Vac, 20 kA at 300 Vdc
• Mounting Type: Rejection style
• Fuse Indicator: Non-indicating
• Material: Melamine tube
• Response Time: 12 seconds minimum at 200% rated current
• Certifications: UL Listed, CSA Certified, CE Marked, RoHS Compliant
• Connection: Ferrule end x ferrule end
• Application: Specialized circuits and industrial control

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LP-CC-20
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Low-Peak
• Type : LP-CC
• Voltage : 600
• Amperage : 20
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 051712180276
• GTIN : 00051712180276
• Country of Origin : Mexico
• Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.15
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
