LP-CC-2-8/10 - Eaton Bussmann 2.8A 600VAC Class CC Time-Delay Fuse, Dual Element, Rejection Style, 200kA Interrupt Rating

LP-CC-2-8/10

LP-CC-2-8/10 is an Eaton Bussmann Class CC time-delay fuse designed for specialized circuits and industrial control applications.This current-limiting, dual-element fuse features a 2.8 amp rating with a voltage rating of 600 VAC and 300 VDC. It has a rejection style design with ferrule end connections and a 200 kA interrupting rating at 600 VAC and 20 kA at 300 VDC. The fuse provides a 12-second time delay at 200% of rated current, ensuring protection against short circuits and overloads while avoiding nuisance trips. It is UL listed, CSA certified, CE marked, and RoHS compliant.

• Amperage: 2.8 A
• Voltage: 600 VAC / 300 VDC
• Class: CC
• Type: Time-delay, dual-element
• Interrupt Rating: 200 kA at 600 VAC, 20 kA at 300 VDC
• Mounting: Rejection style, ferrule end x ferrule end
• Response Time: 12 seconds at 200% rated current
• Material: Melamine tube
• Fuse Indicator: Non-indicating
• Certifications: UL Listed, CSA Certified, CE Marked, RoHS Compliant
• Dimensions: 0.41 in x 1.5 in
• Application: Specialized circuits and industrial control

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LP-CC-2-8/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Low-Peak
• Type : LP-CC
• Voltage : 600
• Amperage : 2
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 051712180559
• GTIN : 00051712180559
• Country of Origin : Mexico
• Dimensions : 0.41 in x 1.5 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.15
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
