LP-CC-2-1/4 - Bussmann, Cooper Bussmann, Eaton 2.25A 600V Class CC Time Delay Dual Element Rejection Fuse

LP-CC-2-1/4

LP-CC-2-1/4 is a Class CC, time-delay, dual-element, current-limiting, rejection-style fuse designed for superior circuit protection.

This Eaton Bussmann Series fuse offers reliable performance with a 2.25A amperage rating, 600V AC voltage rating, and a compact 0.41" x 1.5" size. It features a 12-second minimum time delay at 200% of rated current, making it ideal for protecting small horsepower motor circuits and other sensitive equipment. The fuse is UL Listed, CSA Certified, and CE marked, ensuring compliance with industry standards.

Key Specifications
• Amperage: 2.25A
• Voltage: 600V AC, 300V DC (for 1/2 to 2-8/10A and 20-30A), 150V DC (for 3-15A)
• Poles: 1
• Mounting Type: Rejection base (Class CC)
• Interrupt Rating: 200,000A AC RMS Symmetrical, 20,000A DC
• Series/Frame: LP-CC (Low-Peak)
• Trip Unit: Dual element, time-delay (12 seconds minimum at 200% rated current)
• Certifications: UL Listed (Std. 248-4, Guide JDDZ, File E4273), CSA Certified (Class 1422-02, File 53787), CE, RoHS compliant (for 20-30A)
• Physical Size: 0.41" x 1.5"
• Application: Protection of small horsepower motor circuits and branch circuits
• Type: Current-limiting, time-delay
• Style: Rejection (prevents installation of incorrect fuse types)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LP-CC-2-1/4
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : Low-Peak
• Type : LP-CC
• Voltage : 600
• Amperage : 2
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 005171218050
• GTIN : 00051712180504
• Country of Origin : Mexico
• Dimensions : 0.41 in x 1.5 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.15
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-02
